Подробные спецификации

Категория	Details
Материал	Commonly used stainless steels are 304 and 316L. В some cases, nickel – based stainless steel and titanium are also used.
Shape and Size	Discs and plugs: Diameter ranges from ø1 mm to ø250 mm, with a maximum height of 100 mm. Rings and hollow cylinders: Inner diameter ranges from ø4 mm to ø250 mm, with a maximum height of 1000 mm. Plates: Width can be up to 300 mm, height can be up to 50 mm, larger sizes can be obtained by welding sections. Conical with or without flange: Diameter ranges from ø4 mm to ø100 mm, height ranges from 8 mm to 250 mm.
Filtration Accuracy	Generally 0.5 – 200 μm, and some products can reach 0.2 μm.
Porosity	Usually within the range of 28% – 50%.
Pore Size	Generally 0.5 μm – 160 μm.
Working Temperature	Generally, it can be used continuously in the temperature range from -200°C to 650°C.
Working Pressure	Generally 1.5 – 2.5 Pa, and some high – pressure resistant filters can reach 3.0 MPa or higher.
Flow Rate	Generally 0 – 800 m³/h, and the rated flow rate of some small filters may be 80 – 200 L/min.

Any other sizes can be produced if the drawing provided.

More infomation, please ocntact via email sandy@aegismetals.net +86-15003386113

Особенности

Особенности of the Sintered Stainless Filter | Sintered filter element | Спеченный порошок Filter Element

Durable Материал：Made of 304, 316L stainless steels, etc. It has outstanding corrosion and high – temperature resistance, ensuring long – term use.
Various Shapes & Sizes：Comes in discs, rings, plates, etc., with different dimensions. It can fit different equipment.
Precise Filtration：Achieves 0.5 – 200 μm filtration accuracy, some up to 0.2 μm, separating particles effectively.
Customizable Structure：Porosity 28% – 50%, pore size 4 – 160 μm, customizable for different needs.
Wide – range Conditions：Works from – 200°C to 650°C, 1.5 – 2.5 Pa (up to 3.0 MPa for high – pressure models), and 0 – 800 m³/h flow rate, adaptable to diverse industries.

Применение

Применение of the Sintered Stainless Filter | Sintered filter element | Спеченный порошок Filter Element

Химическая & нефтехимический：Sintered stainless filters purify reaction solutions in the chemical industry. Their high – temperature and corrosion resistance, along with precise filtration, ensure product quality. В petrochemical plants, they filter oil and gas, preventing pipeline blockages.
Еда и напитки：With high – precision filtration and hygiene – friendly features, these filters are used to purify milk, juice, and beer. They can remove particles as small as 0.5 – 200 μm, ensuring product clarity.
More infomation, please ocntact via email sandy@aegismetals.net +86-15003386113
Фармацевтическая：Critical for pharmaceutical manufacturing, they filter liquids, vaccines, and solvents. Some can achieve 0.2 μm accuracy, safeguarding product safety and efficacy.
Водоочистка：В industrial and domestic setups, they filter out suspended solids and rust from various water sources, purifying water for reuse or safe discharge.
